Pressure Switches
Designed for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Diaphragm actuated, 2 poles, 1/4" - 18 NPSF (internal thread).
Features low water cut-off switch to shut off pump at 12 P.S.I. to prevent overheating damage to submersible well pumps. Recommended for submersible pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. The standard action contacts open on rising pressure. Diaphragm actuated - 1/4" 18 NSF internal threads.
Designed for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Includes pulsation plug designed to protect pressure switch components from a plumbing system that may experience water hammer. Diaphragm actuated, 2 poles, 1/4 In. - 18 NPSF (internal thread).
Designed for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Diaphragm actuated, 2 poles, 1/4" - 18 NPSF (internal thread).
Brady nonrepairable style. Zinc-plated steel construction, buna-n diaphragm and air valve. Brass spring and orfice (model No. AV45). Built-in ball check valve (model No. AV100). Temperature maximum 140 deg., pressure maximum 150 P.S.I.
Designed to work in hydropneumatic (air to water) pressure systems where an excess amount of air needs to be released from the tank. Constructed of ABS plastic materials, Brady air releases are noncorrosive, nonconductive, and completely serviceable. The release features an extra large float with removable arm. Release mechanism consists of a buna-n rubber seal, polypropylene ball and 316 stainless steel spring. Factory set at approximately 20 P.S.I., fully adjustable from 0 to 40 P.S.I.
Brady repairable style. Zinc die-cast body. Buna-n diaphragm and cap seal. Brass springs and orfice. Temperature maximum 140 deg.. Pressure maximum 100 P.S.I.
Features low water cut-off switch to shut off pump at 12 P.S.I. to prevent overheating damage to submersible well pumps. Recommended for submersible pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. The standard action contacts open on rising pressure. Diaphragm actuated - 1/4" 18 NSF internal threads.
Designed for the control of electrically driven water pumps. Diaphragm actuated, 2 poles, 1/4" - 18 NPSF (internal thread). 1 per box.
